SIMATIC TP1200 Comfort

Overview

The Siemens SIMATIC TP1200 Comfort is the benchmark 12-inch HMI panel in the SIMATIC Comfort Panel series, designed for direct integration with S7-1500/1200 controllers over PROFINET. Its 12.1-inch widescreen TFT display with 1280×800 resolution and capacitive multi-touch delivers a smartphone-quality interface on the factory floor, while the hardened glass front withstands industrial cleaning agents and satisfies IP65 ingress protection.

All screen development is handled in TIA Portal WinCC Comfort — the same engineering tool used for the S7-1500 PLC in the same project. Tag names are shared automatically: a variable defined in the S7-1500 CPU appears directly in the WinCC tag browser without manual re-entry, and changes to PLC variable names propagate to all HMI screen objects using those tags with a single project compile.

Beyond local display, the TP1200 includes a VNC server enabling remote monitoring from any browser or VNC client, an integrated web server for custom HTML dashboards, and OPC UA client capability to pull data from any OPC UA server on the network — making it a genuine data hub at the machine level, not just a display device.

Key Features

• Seamless TIA Portal integration

  Screen development, tag linking, alarm configuration, and recipe management are all done within the same TIA Portal project as the S7-1500 PLC. Cross-device consistency checks flag mismatched data types before download, eliminating a major commissioning error source.
• Capacitive multi-touch glass

  The projected capacitive touchscreen supports gestures (pinch-zoom, swipe) on specially designed screens. The hardened glass surface is resistant to common industrial solvents and oils, and can be operated with light gloves — removing a barrier that made earlier resistive touchscreens impractical in food and chemical environments.
• Dual PROFINET ports with integrated switch

  Two switched PROFINET ports allow line topology connections — the HMI passes PROFINET traffic to the next device without an external switch. A single IP address covers both ports, simplifying network configuration for linear machine arrangements.
• VNC server & web server built-in

  The integrated VNC server streams the HMI display to any VNC-capable client over Ethernet — enabling remote monitoring from the control room without additional software licensing. The web server serves custom HTML5 dashboards and the WinCC audit trail log directly to browsers.
• Recipe and audit trail management

  WinCC Comfort includes a recipe management function for storing and recalling process parameter sets to the PLC. The audit trail (FDA 21 CFR Part 11 compatible option) logs all operator actions with username, timestamp, and before/after values — mandatory in pharmaceutical and food manufacturing.

Technical Specifications

Typical Applications

• Pharmaceutical manufacturing: 21 CFR Part 11 audit trail + recipe management for batch processes
• Food & beverage: IP65 glass front for washdown environments; glove-friendly multi-touch
• Automotive assembly: TIA Portal integration with S7-1516 for unified machine control
• Water treatment: VNC remote monitoring from SCADA room; OPC UA client to historian
• Panel builder OEMs: Consistent HMI appearance across machine variants using WinCC template libraries
