FL SWITCH 2000 / 3000 Series

Overview

Phoenix Contact's FL SWITCH family spans from the simplest 5-port unmanaged 100 Mbps switches (FL SWITCH 2005) to fully managed Gigabit switches with Parallel Redundancy Protocol (PRP) and High-availability Seamless Redundancy (HSR) — both delivering zero-time recovery with absolutely no packet loss during a network failure. This breadth makes the FL SWITCH family suitable for both budget panel wiring and the most demanding IEC 61850 power-utility and process-safety applications where even 20 ms ring recovery is unacceptable.

The upper-end FL SWITCH 3000G series supports PROFINET Conformance Class C (CC-C), meaning it participates in PROFINET IRT (Isochronous Real-Time) networks with cycle times down to 250 µs and jitter below 1 µs — territory previously limited to specialised IRT-capable switches. This opens isochronous motion control over standard PROFINET infrastructure, reducing the need for dedicated motion network cabling alongside EtherNet/IP or PROFINET RT traffic.

Phoenix Contact's PRONETA Basic and Advanced software provides free topology discovery and configuration management for FL SWITCH networks, similar in concept to Moxa MXview but purpose-built for Phoenix Contact device ecosystems. The web GUI supports SNMP traps, RMON port statistics, and syslog forwarding for integration with enterprise network monitoring platforms.

Key Features

• PRP / HSR — True Zero-Recovery Redundancy — Parallel Redundancy Protocol (IEC 62439-3) sends every frame simultaneously over two independent network paths. The receiver accepts whichever copy arrives first and discards the duplicate — achieving zero packet loss and zero recovery time when one path fails. HSR (High-availability Seamless Redundancy) applies the same principle in ring topologies, eliminating recovery time entirely.
• 22.5 mm Space-Saving DIN-Rail Design — The narrowest FL SWITCH 2005 is just 22.5 mm wide — the same footprint as a standard terminal block. This lets engineers pack eight switches into the same DIN-rail space previously occupied by two conventional switch enclosures, dramatically reducing panel real estate in high-density control cabinets.
• IEEE 1588v2 PTP — Sub-Microsecond Time Sync — The FL SWITCH 3000G series implements IEEE 1588v2 Precision Time Protocol as a boundary clock with hardware timestamping, achieving sub-microsecond clock synchronisation accuracy. This enables simultaneous sampling from distributed sensors for power quality analysis, disturbance recording, and synchronised motion across multi-axis machines.
• Broad Product Range — Unmanaged to Managed — A single vendor family covers the entire network from the field level (unmanaged 5-port FL SWITCH 2005) through cell level (8-port managed FL SWITCH 3008T) to site backbone (Gigabit PRP/HSR FL SWITCH 3000G). Mixed topologies use the same PRONETA configuration tool regardless of model, simplifying commissioning and spare-part stocking.

Technical Specifications

Application Areas

• IEC 61850 substation automation and protection relay networks (PRP/HSR)
• PROFINET IRT high-speed motion and robotics (CC-C, Gigabit)
• Panel-mounted device-level networks (unmanaged 5-port, 22.5 mm)
• Process industry DCS field device networks (−40°C rated)
• Marine and offshore classification-certified networks (DNV GL)
